DG/S2.64.1.1 KNX DALI Gateway 2-fold
€429,00
In stock
DG/S2.64.1.1 KNX DALI Gateway 2-fold: Dual-Output DALI-2 Controller
The gateway simplifies installation by including an integrated DALI power supply for both outputs. Its advanced functionality allows for precise lighting management via KNX, controlling 2×64 individual participants, 2×16 lighting groups, or 2×16 scenes across the two lines.
The DG/S2.64.1.1 KNX DALI Gateway 2-fold ensures safety compliance by supporting self-contained emergency converters (DT1), enabling the triggering of function and duration emergency tests via KNX, along with providing extensive fault and error messages.
1. DG/S2.64.1.1 KNX DALI Gateway 2-fold: High Capacity and Emergency Support
This dual-channel DALI Gateway offers scalability and critical features for large-scale, modern lighting control systems.
DALI-2 Compliance and Capacity:
- Output Count: Two independent DALI outputs (2-fold), each operating as a Single-Master Controller.
- Total Capacity: Manages up to 2×64 DALI participants (128 devices total).
- Integrated Power: Integrated DALI power supply for both lines, DALI-2 certified (EN 62386).
- Control Structure: Supports control via 2×64 individual DALI addresses, 2×16 groups, 2×16 scenes, and broadcast commands.
Advanced Features and Diagnostics:
- Emergency Lighting: Supports self-contained emergency converter DT1 (EN 62386-202), facilitating mandatory emergency lighting tests via KNX.
- Functions: Integrated advanced functions including Slave, Staircase, Force, Block, and Scene, plus extensive fault and error messages.
- Diagnostics: A separate software tool (ABB i-bus® Tool) is available for configuration and debugging, including DALI address and group assignment.
2. Technical Details and Installation
Designed for compact integration into standard electrical panels.
- Installation: Designed for professional DIN-Rail installation.
- Dimensions: Extremely compact, occupying only 4 modular spacings (70 mm width, 90 mm height).
- Power: Wide range Auxiliary Voltage of 110 … 230 V AC, with a total power loss of 4 W.
- Compatibility: Interfaced with the KNX (TP) bus. Control commands can originate from a KNX Touch Panel or a KNX Multi-function Sensor .
