EAE DA110 DALI Gateway

Description

Introduction

The EAE DA110 DALI Gateway serves as a reliable interface connecting the KNX system with the DALI bus network. Designed with an integrated DALI power supply, this gateway simplifies installation and maintains compliance with the IEC 62386 standard for seamless lighting control integration. This device is part of our KNX Actuators range.

Unlike the DA100 model, the DA110 offers granular, individual control over each connected DALI load across the network. System configurators can manage up to 64 DALI devices—including LED drivers and Fluorescent-ECG units—while utilizing the EAE DALI Commissioning Tool for complete addressing and grouping setup.

Key Features

• KNX to DALI Bus Interface: Direct communication bridge operating between KNX and DALI protocols.
• Up to 64 DALI Devices: Controls up to 64 DALI-compliant loads, such as LED drivers and Fluorescent-ECG units.
• Individual Device Control: Distinguishes itself from the DA100 by supporting individual load management.
• 16 Lighting Scenes: Configurable support for up to 16 lighting scenes across the system.
• EAE DALI Commissioning Tool: Specialized software setup for precise DALI addressing and grouping operations.
• IEC 62386 Compliance: Fully compliant with international DALI standard specifications.

Benefits

• Granular Individual Control: Enables individual addressing and management of up to 64 connected DALI devices.
• Integrated Power Supply: Features a built-in DALI power supply to streamline hardware requirements across the DALI line.
• Standards Compliant: Designed to fully comply with the IEC 62386 standard for standardized DALI bus communication.
• Advanced Fault Monitoring: Permits real-time fault status monitoring of connected DALI devices using dedicated KNX group objects.
• Flexible Scene Management: Supports up to 16 configurable lighting scenes for customizable lighting control.

Technical Specifications

Specification	Value
Manufacturer	EAE
Model	DA110
Standard	IEC 62386
Connectable DALI Devices	Up to 64
Lighting Scenes	16

Applications

• Commercial Building Lighting: Managing individual DALI LED drivers and fluorescent lighting fixtures integrated into a KNX automation system.
• Flexible Lighting Scene Systems: Creating up to 16 distinct scene configurations for multi-purpose commercial spaces and office environments.

Installation Notes

• Commissioning Tool Usage: DALI addressing and grouping setup must be executed using the official EAE DALI Commissioning Tool.
• Bus Wiring Integration: Connect the gateway directly between the KNX bus and the DALI line, taking advantage of the integrated DALI power supply.
• Device Capacity Check: Ensure connected DALI loads (such as LED drivers and Fluorescent-ECGs) do not exceed the 64-device limit on the DALI line.

Developer Resources

• EAE DALI Commissioning Tool for system setup, addressing, and grouping operations.
• KNX group object structure for individual device control and DALI device fault status monitoring.

FAQ

How does the EAE DA110 differ from the DA100 model?

Differing from the DA100 model, the DA110 allows individual control for each connected DALI load on the DALI bus. Explore more products from EAE for professional building automation projects.

How many DALI devices can be connected to the EAE DA110 Gateway?

The gateway supports up to 64 connected DALI devices, including LED drivers and Fluorescent-ECG units. For certificates and current technical files, refer to the official product documentation.

Does the EAE DA110 require an external DALI power supply?

No, the EAE DA110 features an integrated DALI power supply.

How are DALI addressing and grouping managed for this gateway?

System setup, including DALI addressing and grouping operations, is executed using the EAE DALI Commissioning Tool.

What is the exact product model?

The order/model code for this page is SMP DA110. Match it against project documents before purchase.

Who is the manufacturer?

This product is manufactured by EAE.

Conclusion

The EAE DA110 DALI Gateway provides a versatile link between KNX systems and DALI lighting loads, offering individual control for up to 64 devices and support for 16 scenes. Installers and system integrators can review our professional project support options.

Compliant with IEC 62386 and equipped with an integrated DALI power supply, it streamlines commissioning via the EAE DALI Commissioning Tool and improves maintenance through KNX fault status monitoring.
