EAE IPR200 KNX IP Router: TP to IP Gateway for Commissioning and Backbone
1. Key Features and Advanced Connectivity
The EAE IPR200 KNX IP Router is built for high performance and system diagnostics, offering powerful control over data flow.
Routing, Tunneling, and Isolation:
- Dual Functionality: Operates as both an IP Router (for backbone/line coupling) and an IP Tunneling interface (for ETS access).
- Simultaneous Connections: Allows up to 4 simultaneous KNXnet/IP connections, enabling multiple users (e.g., ETS, visualizations, and monitoring tools) to access the KNX installation.
- Electrical Insulation: Provides galvanic isolation between the KNX bus line and the IP network, enhancing system safety.
Filtering and Diagnostics:
- Configurable Filtering: Features the option to block or allow telegrams between KNX and IP networks based on a configured filter table, optimizing traffic.
- Quick Diagnosis Override: A dedicated on-device button allows for the deactivation of the filter table, which is invaluable for quick diagnosis and commissioning.
- Status LEDs: Provides essential functional status information with 6 LEDs on the device, including IP status, KNX bus traffic, and communication errors.
2. Technical Specifications
| Specification | Detail |
|---|---|
| Model | IPR200 KNX IP Router |
| Functionality | Routing (Coupler) & Tunneling Interface |
| KNXnet/IP Connections | 4 Simultaneous Connections (Tunneling) |
| IP Assignment | DHCP or Static IP |
| Isolation | Electrical Insulation between IP and KNX TP |
| Filtering | Configurable Filter Table (Block/Allow) |
