Inspinia 8″ SQ Touch Panel | INS8SQ | Smart Home & BMS Hub

The INS8SQ (Inspinia 8” SQ) is a sophisticated, high-performance touch panel designed to be the central control point for modern smart home and building automation. Featuring a brilliant 8-inch IPS display with a 1280 x 800 resolution, the Inspinia INS8SQ provides an elegant and intuitive interface for managing complex systems. Driven by a Quad-Core processor and running Android 7.1, this panel is built to handle up to 2000 BMS points and 1000 UI objects, ensuring a smooth and responsive user experience.Versatility is at the core of the INS8SQ, offering seamless integration with industry-standard protocols such as KNX, Modbus, and Zigbee 3.0. Equipped with built-in temperature and humidity sensors, digital I/O, and intercom support, this Inspinia touch panel from the SQ Series is the professional choice for those seeking a compact yet powerful command center for residential or commercial automation.

1. INS8SQ: Seamless Automation & Multi-Protocol Control

A sleek, horizontal-mode interface engineered for deep system integration and precise environmental monitoring.

Powerful Hardware & Licensing:

Optimized Display: 8” IPS touchscreen with 300 cd/m2 luminance and 5-point capacitive touch for premium tactile feedback.
Advanced Logic Engine: Pre-loaded with the Inspinia application, supporting 500 BMS points initially (expandable up to 2000 points).
Integrated Multimedia: Features 2x 2-Watt speakers and a high-sensitivity microphone input, perfectly suited for intercom and door entry systems.
Environmental Sensing: Built-in industrial-grade sensors for humidity (0-100% RH) and temperature (-40°C to +125°C).

Connectivity & Optional Expansion:

Rich Standard Interfaces: Includes 1x LAN RJ45 port, 5x Digital Inputs, and 2x Digital Outputs (Dry Contact 2A) for local control.
Universal Protocol Support: Two optional add-on ports allow for KNX TP, Bticino (SCS), iNELS Bus, Zigbee 3.0, and VRF integration.
Flexible Powering: Supports 24V DC input or PoE (IEEE 802.3at) for a clean, single-cable installation with max 12W consumption.
RS485 Modbus: Available galvanic isolated RS485 for reliable communication with industrial meters and HVAC systems.

2. Technical Specifications and Hardware Limits

Consult the detailed parameters of the INS8SQ to plan your smart building hierarchy effectively.

Feature	Specification Details
Product Reference	INS8SQ
Display	8″ IPS (1280 x 800) Horizontal Mode
BMS Capacity	2000 Points Max (500 Points Initial License)
Hardware	Quad-Core 1.2 GHz / 1GB RAM / 8GB Flash
Power Supply	24 VDC or PoE (802.3at)
Digital I/O	5x Digital In / 2x Digital Out (2A)
Operating Temp	-10°C to +50°C
