Inspinia IP Security Console Intercom (INS-SCA24)

Description

Introduction

The Inspinia IP Security Console Intercom (SKU: INS-SCA24) is a feature-packed master station designed for centralized building management, communication, and access control. Operating on an Android-based system with 512 MB RAM and 4 GB ROM, this console provides guard stations and security personnel with an intuitive interface to oversee residential and commercial premises. Explore more Inspinia building automation products for professional building automation projects.

Equipped with a 10.1-inch capacitive touch screen with 1024×600 resolution, the INS-SCA24 supports video monitoring for up to 16 IP cameras and features seamless SIP protocol integration. With flexible power options including Power over Ethernet (PoE 802.3af) and DC 12V/2A, it integrates smoothly into modern IP-based building infrastructures.

Key Features

• 10.1-inch capacitive TFT LCD display with 1024×600 resolution.
• Android-based operating system with 512 MB RAM and 4 GB ROM.
• Monitoring support for up to 16 IP cameras via H.264 codec.
• Integrated 0.3 MP CMOS camera and built-in speaker with echo cancellation.
• 1 x RJ45 10/100 Mbps adaptive Ethernet port.
• Supported network protocols: SIP, UDP, TCP, RTP, RTSP, NTP, DNS, HTTP, DHCP, IPv4, ARP, ICMP.
• Power supply flexibility via PoE (802.3af) or DC 12V/2A.
• Desktop mounting design with compact dimensions of 303 x 195 x 35 mm.

Benefits

• Centralized Security Monitoring: Supports video streaming and monitoring for up to 16 IP cameras using H.264 video codec.
• SIP 2.0 Interoperability: Ensures seamless communication across SIP-enabled intercoms, access control devices, and guard stations.
• Flexible Power Options: Utilizes PoE (802.3af) or DC 12V/2A for versatile installation setups.
• Clear Touch Navigation: Features a 10.1-inch 1024×600 TFT LCD capacitive display for clear visuals and intuitive operation.
• Enhanced Audio Clarity: Integrated microphone and built-in speaker with echo cancellation utilizing the G.711 audio codec.
• Streamlined Operations: Efficiently handles alarms, call logs, messaging, and resident notifications from a single interface.

Technical Specifications

Specification	Value
Hardware / Software Operating System	Android based system Memory : 512 MB RAM / 4GB ROM Power Supply: PoE (802.3af) or DC 12V/2A
Operating System	Android based system Memory : 512 MB RAM / 4GB ROM Power Supply: PoE (802.3af) or DC 12V/2A
Camera and Video Resolution	0.3 MP CMOS , 1024 x 600 pixels Video Codec: H.264 Supports monitoring of up to 16 IP cameras
Resolution	0.3 MP CMOS , 1024 x 600 pixels Video Codec: H.264 Supports monitoring of up to 16 IP cameras
Connectivity Ethernet	1 x RJ45, 10/100 Mbps adaptive Protocols: SIP, UDP, TCP, RTP, RTSP, NTP, DNS, HTTP, DHCP, IPv4, ARP, ICMP
Ethernet	1 x RJ45, 10/100 Mbps adaptive Protocols: SIP, UDP, TCP, RTP, RTSP, NTP, DNS, HTTP, DHCP, IPv4, ARP, ICMP
Audio Features Audio Codec	G.711 Microphone : Built-in Speaker : Built-in with echo cancellation
Audio Codec	G.711 Microphone : Built-in Speaker : Built-in with echo cancellation
Working Temperature & Humidity Temperature	-10℃ to +55℃ Humidity : 10% to 90% (non-condensing)
Temperature	-10℃ to +55℃ Humidity : 10% to 90% (non-condensing)
Desktop mounting Product Dimensions	303 x 195 x 35 mm

Applications

• Residential Guard Stations: Master station for managing resident calls, messaging, alarms, and call logs.
• Commercial Security Desks: Central station for IP camera monitoring and cross-system SIP communication.

Installation Notes

• Designed for desktop mounting with overall physical dimensions of 303 x 195 x 35 mm.
• Connect to the network via standard RJ45 cable powered by PoE (802.3af) or a local DC 12V/2A power adapter.
• Operate within the specified temperature range of -10°C to +55°C and relative non-condensing humidity of 10% to 90%.

Developer Resources

• Data Sheet
• Brochure
• CE Declaration

FAQ

What power supply options are available for the Inspinia INS-SCA24?

The console can be powered using standard PoE (802.3af) over Ethernet or via an external DC 12V/2A power adapter. For certificates and current technical files, refer to the manufacturer technical documentation.

How many IP cameras can be monitored using this console?

The console supports live monitoring of up to 16 IP cameras utilizing the H.264 video codec.

Which network protocols are supported by the device?

Supported protocols include SIP, UDP, TCP, RTP, RTSP, NTP, DNS, HTTP, DHCP, IPv4, ARP, and ICMP.

What is the exact product model?

The order/model code for this page is INS-SCA24. Match it against project documents before purchase.

Who is the manufacturer?

This product is manufactured by Inspinia.

Where can I find the official technical documentation?

Use the manufacturer product page and datasheets for this exact SKU. Always verify the latest revision before specifying the product.

Conclusion

The Inspinia IP Security Console Intercom (INS-SCA24) provides an effective centralized platform for intercom management, access communication, and multi-camera IP video monitoring in commercial and residential facilities. Installers and system integrators can review our dealer and project support options.
