Panasonic KNX Input Module 20 Gang Dry-Contact IO100 (WRKT4000E5NC)

Description

Introduction

The Panasonic KNX Input Module 20 Gang Dry-Contact IO100 (SKU: WRKT4000E5NC) is a DIN-rail mounted KNX system component designed to interface conventional contacts with a KNX building automation network. Equipped with 20 dry-contact channels, this module transmits switch, button, and contact signals directly to the KNX line, facilitating robust control across lighting, shutter/blind systems, and security monitoring setups. This device is part of our KNX automation components range.

Operating directly on the standard KNX bus voltage (21–32 V DC) with an IP20 protection rating, the IO100 input module offers reliable operation across ambient temperatures from -5 °C to +45 °C. For system integrators and procurement teams, verifying exact model specifications (WRKT4000E5NC) against project BOQs and manufacturer documentation ensures seamless integration and accurate hardware provisioning for complex commercial or residential automation scenarios.

Key Features

• – 20 dry-contact input channels for comprehensive signal integration.
• – Powered via standard KNX Bus line voltage (21–32 V DC).
• – Standard DIN-rail mounting for organized panel installation.
• – Operating ambient temperature range of -5 °C to +45 °C.
• – Enclosure rated for IP20 protection.
• – Supports individual channel addressing and parametric configuration.
• – Transmits switch, button, alarm, scene, and status feedback signals.

Benefits

• – High Channel Capacity: Integrates 20 dry-contact inputs into a single compact module, optimizing distribution cabinet space.
• – Flexible Parameter Control: Each channel can be individually addressed and parametrically configured for tailored automation logic.
• – Versatile Signal Transmission: Converts mechanical switches, pushbuttons, or dry contacts into KNX signals for scenes, alarms, and status feedback.
• – Direct Bus Powering: Operates directly off the KNX bus line (21–32 V DC), simplifying panel wiring.
• – Accurate Procurement Matching: Exact SKU WRKT4000E5NC ensures precise verification against engineering bills of quantities (BOQ).

Applications

• – Lighting and Scene Control: Interfaces standard mechanical switches and pushbuttons to trigger KNX switching, dimming, and lighting scenes.
• – Blinds and Shutter Automation: Connects conventional shutter controls to transmit directional positioning signals across the KNX network.
• – Security and Status Monitoring: Integrates dry-contact alarm outputs and auxiliary status contacts for real-time system feedback.

Installation Notes

• – Mounting & Environment: Mount securely on a standard DIN-rail within an enclosure that meets IP20 protection guidelines, ensuring ambient operating temperatures remain between -5 °C and +45 °C.
• – Bus Wiring: Connect directly to the standard KNX bus line (21–32 V DC), verifying polarity and channel wiring before powering the system.
• – Documentation Reference: Refer to the official WRKT4000E5NC Reference Manual and Installation Manual to ensure exact ETS parameter assignment and BOQ compliance.

Developer Resources

• Official technical documentation including the WRKT4000E5NC KNX Input Module Reference Manual and Operating & Installation Manual are available from Panasonic to support ETS parameterization, channel addressing, and system integration.

FAQ

What is the primary function of the Panasonic WRKT4000E5NC input module?

It translates contact triggers from 20 dry-contact inputs into standard KNX bus signals for controlling lighting, blinds, alarms, and status feedback. Explore more products from Panasonic for professional building automation projects.

What is the operating voltage requirement for this module?

The module operates directly on the KNX Bus line voltage ranging from 21 V DC to 32 V DC. For certificates and current technical files, refer to the official product documentation.

What form factor and protection rating does the device feature?

The module features standard DIN-rail mounting and an IP20 ingress protection rating.

What is the specified operating temperature range?

The device is rated for operation in ambient temperatures between -5 °C and +45 °C.

What is the exact product model?

The order/model code for this page is WRKT4000E5NC. Match it against project documents before purchase.

Who is the manufacturer?

This product is manufactured by Panasonic.

Conclusion

The Panasonic KNX Input Module 20 Gang Dry-Contact IO100 (WRKT4000E5NC) offers a practical solution for incorporating 20 dry-contact inputs into KNX automation networks. With its DIN-rail enclosure, bus-powered operation, and individual channel parameterization, it serves as an effective interface for lighting, blind control, and status monitoring. Installers and system integrators can review our dealer and project support options.

To prevent misorders and streamline installation, technical buyers should cross-reference SKU WRKT4000E5NC against project documentation and consult the official Panasonic manuals during commissioning.
