ABB DG/S1.64.1.1 DALI Gateway, Basic, 1-fold, MDRC

Description

Introduction

The ABB DG/S1.64.1.1 is a DALI Gateway, Basic, 1-fold, MDRC for KNX gateway applications. It is a Single-Master DALI Controller certified according to DALI-2 (EN 62386) and is used to control DALI or DALI-2 standard devices via ABB i-bus® KNX.

For lighting control projects, the DG/S1.64.1.1 provides one DALI output for up to 64 DALI participants, with the DALI power supply integrated. Control and status feedback are carried out via KNX per DALI participant, by lighting groups, in broadcast, or through scenes.

Key Features

• Brand: ABB.
• SKU and model: DG/S1.64.1.1.
• Product ID: 2CDG110198R0011.
• Catalog description: DG/S1.64.1.1 DALI Gateway, Basic, 1-fold, MDRC.
• Communication interface: DALI.
• Compatible bus system: KNX (TP).
• Number of outputs: 1.
• Manual operation: Yes; software updateable: Yes; number of LEDs: 1; number of batteries: 0.

Benefits

• Connects DALI or DALI-2 standard devices to ABB i-bus® KNX for integrated building automation control.
• Supports one DALI output for up to 64 DALI participants, helping consultants and integrators define the gateway position clearly in the BOQ.
• Integrated DALI power supply reduces the need to specify a separate DALI power supply for the supported output.
• Provides KNX-based control and status feedback per DALI participant, by 16 lighting groups, in broadcast, or via 16 scenes.
• Includes extensive fault and error messages for supported DALI installations.
• Supports integrated slave, staircase, force, block, and scene functions.
• Supports self-contained emergency converter DT1 according to EN 62386-202, with emergency tests such as function and duration tests triggerable by means of KNX and emergency converter.

Technical Specifications

Specification	Value
Extended Product Type	DG/S1.64.1.1
Product ID	2CDG110198R0011
Display Name	DG/S1.64.1.1
Instructions and Manuals	2CDG941167P0001
Number of Outputs	1
Number of LEDs	1
Manual Operation	Yes
Number of Batteries	0
E-Number (Norway)	4544214
E-Number (Sweden)	1739089
Declaration of Conformity – CE	2CDK507168D2701
EAN	4016779942669
Manufacturer Description	Single-Master DALI Controller certificated acc. to DALI-2 (EN 62386). The device is used to control DALI or DALI-2 standard devices via ABB i-bus® KNX. One DALI output for up to 64 DALI participants. The DALI power supply is integrated. Control and status feedback is carried out…
Catalog Description	DG/S1.64.1.1 DALI Gateway, Basic, 1-fold, MDRC
Degree of Protection	IP20
Communication Interface	DALI
Compatible Bus Systems	KNX (TP)
Product Range	KNX
EPLAN Data	9AAC189178_EPLAN
E-Number (Finland)	2815584
E-Number (Switzerland)	405670305
SCIP	202aa237-cd1a-4cd1-8f22-4e17f0717ba9 Germany
WEEE B2C / B2B	Business To Consumer
ETIM 9	EC001099 – System interface/media gateway for bus system
ETIM 10	EC001099 – System interface/media gateway for bus system

Applications

• KNX lighting control projects that require control of DALI or DALI-2 standard devices through ABB i-bus® KNX.
• Commercial and professional building automation specifications where one DALI output for up to 64 DALI participants is required.
• Projects requiring KNX-based status feedback, lighting groups, broadcast control, scenes, and fault or error messaging for DALI participants.
• Installations using supported self-contained emergency converter DT1 according to EN 62386-202, including supported emergency test triggering.

Installation Notes

• Verify the exact SKU DG/S1.64.1.1, Product ID 2CDG110198R0011, and EAN 4016779942669 against the project BOQ before ordering.
• Plan the DALI side according to the documented one DALI output and the stated capacity of up to 64 DALI participants.
• Use the supported KNX control structure during design: per DALI participant, 16 lighting groups, broadcast, and 16 scenes.
• Refer to ABB Instructions and Manuals document 2CDG941167P0001 and the manufacturer product page before installation, commissioning, or substitution.
• Note the stated Degree of Protection: IP20, and confirm suitability against the project enclosure and installation requirements.

Developer Resources

• Manufacturer product page: https://new.abb.com/products/en/2CDG110198R0011/dg-s-1-64-1-1.
• Instructions and Manuals reference: 2CDG941167P0001.
• Declaration of Conformity – CE reference: 2CDK507168D2701.
• EPLAN Data reference: 9AAC189178_EPLAN.
• EAN: 4016779942669.
• E-Number Norway: 4544214; E-Number Sweden: 1739089; E-Number Finland: 2815584.

FAQ

What is the ABB DG/S1.64.1.1 used for?

The ABB DG/S1.64.1.1 is used to control DALI or DALI-2 standard devices via ABB i-bus® KNX. Explore more ABB automation devices for professional building automation projects.

How many DALI participants does the DG/S1.64.1.1 support?

It has one DALI output for up to 64 DALI participants. For certificates and current technical files, refer to the official product documentation.

Does the ABB DG/S1.64.1.1 include a DALI power supply?

Yes. The product description states that the DALI power supply is integrated.

Which bus system is listed as compatible with this gateway?

The compatible bus system listed for the ABB DG/S1.64.1.1 is KNX (TP).

Which official document references should be checked before ordering?

Check the ABB manufacturer product page, Instructions and Manuals reference 2CDG941167P0001, Product ID 2CDG110198R0011, and EAN 4016779942669 to ensure the correct item is specified.

What is the exact product model?

The order/model code for this page is DG/S1.64.1.1. Match it against project documents before purchase.

Conclusion

The ABB DG/S1.64.1.1 DALI Gateway, Basic, 1-fold, MDRC is a documented ABB i-bus® KNX gateway for controlling DALI or DALI-2 standard devices, with one DALI output for up to 64 DALI participants and integrated DALI power supply. Installers and system integrators can review our installer purchasing support options.

For accurate procurement, match the SKU DG/S1.64.1.1, Product ID 2CDG110198R0011, and official ABB documentation before placing the order.
