Introduction
The EAE RCU0800 Room Control Unit is a versatile, all-in-one KNX actuator designed to manage essential room automation functions from a single compact interface. Engineered for modern building automation projects, this unit simplifies installation by serving as a unified controller for lighting circuits, AC/DC motorized blinds, and fan coil climate control systems. This device is part of our KNX system components range.
Operating directly off the KNX bus without requiring an external auxiliary power supply, the RCU0800 ensures straightforward deployment and reduced wiring complexity. It complies with EN 60669 standards for switching resistive, capacitive, and inductive loads, while offering advanced software functions including staircase logic, priority management, operating hour tracking, and threshold control.
Key Features
- 8x16A rated output channels for load switching and motor control.
- Support for 2-point and 3-point valve fan coil units.
- AC and DC motorized blind and shutter control capabilities.
- Integrated staircase lighting control with adjustable timing functions.
- External logic gate integration, priority control, and threshold switching.
- Operating hour tracking for connected electrical loads.
Benefits
- Unified control for lighting, AC/DC blind actuators, and fan coil climate systems in one device.
- Bus-powered design eliminates the need for an external auxiliary power supply unit.
- Compliant with EN 60669 standards for handling resistive, capacitive, and inductive electrical loads.
- Integrated logic functions reduce system complexity and the need for separate logic modules.
- Built-in operating hour counter enables effective preventive maintenance tracking.
- Configurable priority and sweep control features enhance energy management and emergency overrides.
Technical Specifications
Applications
- Hotel guest rooms requiring consolidated control of lighting, climate, and window coverings.
- Commercial office spaces designed for integrated lighting, HVAC valve control, and blind automation.
- Residential buildings seeking a space-saving multi-function KNX room control actuator.
Installation Notes
- Ensure installation is conducted in accordance with EN 60669 standards for switching electrical loads.
- Connect directly to the KNX bus line; no additional external auxiliary power supply unit is required.
- Verify output channel assignments in ETS for lighting, blind control, or fan coil valve configurations before energizing.
Developer Resources
- Download the official ETS product database file from EAE Technology for parametric configuration.
- Review manufacturer technical documentation for specific logic gate and threshold parameter setups.
FAQ
Does the EAE RCU0800 require an external power supply?
No, the EAE RCU0800 operates directly from the bus line without requiring an external power supply. Explore more EAE building automation products for professional building automation projects.
What load types can the EAE RCU0800 switch?
It is rated for switching resistive, capacitive, and inductive loads in compliance with EN 60669.
What types of fan coil valves are supported by this unit?
The RCU0800 supports both 2-point and 3-point valve fan coil systems.
What output capacity does the EAE RCU0800 offer?
The device features 8 output channels rated at 16A each.
What is the exact product model?
The order/model code for this page is SMP RCU0800. Match it against project documents before purchase.
Who is the manufacturer?
This product is manufactured by EAE.
Conclusion
The EAE RCU0800 Room Control Unit stands out as a highly efficient, multi-functional KNX actuator for modern room control applications. By consolidating lighting, blind, and fan coil management into an 8x16A bus-powered unit, it significantly streamlines system architecture. Installers and system integrators can review our professional project support options.
With compliance to EN 60669 and a complete suite of embedded logic functions, the RCU0800 provides system integrators with a reliable, space-saving solution for commercial and hospitality projects.
