Panasonic KNX Dimming Actuator 4 Channel 250W DM104 (WRKT5414J5NC)

Description

Introduction

The Panasonic KNX Dimming Actuator 4 Channel 250W DM104 (SKU: WRKT5414J5NC) is designed for stepless and precise lighting control within KNX building automation systems. Suitable for halogen, LED, and fluorescent lighting, this 4-gang dimming module optimizes energy efficiency across commercial and residential projects. This device is part of our KNX automation components range.

When procuring KNX infrastructure products, verifying exact model specifications and matching bill of quantities (BOQ) requirements is essential to prevent ordering errors. Consultants and integrators should reference official Panasonic documentation and installation guides to confirm that this 250W 4-channel dimming unit meets project details.

Key Features

• 4-channel dimming output with 250W capacity per gang (Model DM104)
• 1–10V or phase control dimming modes
• Independent channel configuration parameters
• Integrated LED status indicators
• Physical manual control buttons on device
• Time programming functionality
• Scene recall capabilities
• Adjustable dimming curve settings

Benefits

• Stepless Light Level Adjustment: Provides smooth and precise dimming control to increase energy efficiency.
• Broad Lighting Compatibility: Supports halogen, LED, and fluorescent light sources.
• Independent Channel Control: Allows individual channel configuration tailored to specific lighting circuits.
• Manual Local Control: Features manual pushbuttons and status LEDs for easy operation and verification.
• Advanced Control Functions: Integrated support for time programming, scene recall, and custom dimming curve adjustments.
• Accurate Procurement Matching: Clearly identified by SKU WRKT5414J5NC and model DM104 to streamline BOQ verification.

Applications

• Commercial and Residential Lighting Control: Managing brightness levels for halogen, LED, and fluorescent lighting fixtures in KNX systems.
• Automated Scene and Timed Control: Implementing scheduled light routines and custom lighting scenes across building automation installations.
• Energy Management Projects: Precise light intensity modulation designed to optimize energy consumption.

Installation Notes

• Verify exact project requirements and cross-reference SKU WRKT5414J5NC against the bill of quantities prior to installation.
• Consult the official Panasonic KNX Dimming Actuator 4 Gang 250W DM104 Installation and User Manual for exact wiring diagrams.
• Ensure parameter setup in ETS matches the connected load types and dimming configuration per channel.

Developer Resources

• Panasonic KNX Dimming Actuator 4 Gang 250W DM104 Reference Guide
• Panasonic KNX Dimming Actuator 4 Gang 250W DM104 Installation and User Manual

FAQ

Which lighting types are compatible with the Panasonic WRKT5414J5NC dimming actuator?

This actuator offers wide compatibility with halogen, LED, and fluorescent lighting sources. Explore more Panasonic automation devices for professional building automation projects.

What dimming methods are supported by the DM104 actuator?

The device supports 1–10V or phase control dimming with independent channel configuration. For certificates and current technical files, refer to the manufacturer technical documentation.

How can I verify I am specifying the correct product version?

Check the exact manufacturer SKU WRKT5414J5NC and model code DM104 against official Panasonic technical documentation and your project BOQ.

Does this KNX actuator include physical local controls?

Yes, it includes built-in manual control buttons and LED status indicators for manual device operation.

What is the exact product model?

The order/model code for this page is WRKT5414J5NC. Match it against project documents before purchase.

Who is the manufacturer?

This product is manufactured by Panasonic.

Conclusion

The Panasonic KNX Dimming Actuator 4 Channel 250W DM104 (WRKT5414J5NC) delivers adaptable phase or 1-10V control, scene management, and time programming for professional KNX installations. Installers and system integrators can review our become a KNX dealer options.

To ensure correct procurement and avoid ordering discrepancies, confirm all technical documentation and BOQ references prior to purchase.
