The Schneider SpaceLogic KNX Binary Input REG-K/8×10 (MTN644592) is a professional system component designed to interface conventional push-buttons, switches, and floating contacts directly into a KNX building automation system. Featuring 8 independent binary input channels, this unit provides signal voltage supply to connected inputs, allowing seamless integration of physical switching states into central control routines. This device is part of our KNX system components range.
Engineered within Schneider’s SpaceLogic KNX series, the device comes in a light grey plastic enclosure designed for standard DIN rail mounting across 4 modules (18 mm each). With an IP20 protection rating and clear LED status signaling directly on the device, system integrators gain a reliable, space-efficient solution that simplifies installation and enhances central energy management.
Key Features
- Part of the Schneider SpaceLogic KNX product series.
- 8 binary / digital inputs for conventional potential-free contacts.
- Signal voltage supply provided to connected inputs.
- Occupies 4 standard 18 mm modules on a DIN rail.
- IP20 ingress protection rated light grey plastic housing.
- Integrated LED indicators for local signal status display.
- Nominal operating voltage [Ue] rated at 10 V AC 50 Hz.
Benefits
- Connects up to 8 conventional push-buttons, switches, or floating contacts to the KNX bus line.
- Integrated signal voltage supply simplifies contact wiring and eliminates extra external power sources for inputs.
- Facilitates centralized building control and energy optimization to help lower overall operational costs.
- Saves installation time and cabinet space with a compact 4-module (18 mm) DIN rail footprint.
- On-device status LEDs provide clear visual feedback for immediate channel diagnostics during commissioning.
- Sustainable design backed by an 18-month manufacturer warranty and recycled packaging materials.
Technical Specifications
Applications
- Integration of conventional wall push-buttons, toggle switches, and sensor contacts into KNX automation networks.
- Centralized status monitoring and binary signal collection inside electrical control panels for commercial and residential buildings.
Installation Notes
- Mount the device directly onto a standard DIN rail inside a protective distribution box offering at least IP20 protection.
- Ensure total enclosure space allows for 4 module widths (18 mm per module).
- Wire the 8 binary inputs according to the SpaceLogic KNX wiring guidelines, using the internal signal voltage output provided by the unit.
Developer Resources
- Configured via standard ETS software tool using official Schneider SpaceLogic KNX product database files.
FAQ
How many binary inputs are provided on the Schneider MTN644592?
The Schneider MTN644592 features 8 independent binary/digital input channels for connecting floating contacts or standard push-buttons. Explore more Schneider building automation products for professional building automation projects.
What is the module size and mounting style for this unit?
The module is designed for DIN rail mounting and occupies a total width of 4 standard 18 mm modules. For certificates and current technical files, refer to the official Schneider product page.
Does the MTN644592 binary input module include visual diagnostics?
Yes, the unit features local status LEDs on the front panel for clear signalization and diagnostic monitoring.
What is the standard warranty period for this Schneider product?
This product comes with an 18-month official warranty from Schneider Electric.
What is the exact product model?
The order/model code for this page is MTN644592. Match it against project documents before purchase.
Who is the manufacturer?
This product is manufactured by Schneider.
Conclusion
The Schneider SpaceLogic KNX Binary Input REG-K/8×10 (MTN644592) offers a highly reliable and efficient solution for bringing 8 discrete binary signals into a KNX automation system. Its standard 4-module DIN rail design, local LED diagnostics, and signal voltage supply make it an essential component for streamlined building control installations. Installers and system integrators can review our professional project support options.
