theben iONprime CP4 KNX Room Controller (4969300)

Description

Introduction

The theben iONprime CP4 KNX (SKU: 4969300) is an advanced KNX TP room controller designed for comprehensive climate and lighting management in modern building automation. Equipped with an integrated temperature controller and environmental sensors for temperature, relative humidity, proximity, and ambient brightness, this controller provides complete environmental feedback within a compact wall-mounted unit. This device is part of our KNX Touch screen range.

Featuring a clear 4-inch touch display with a resolution of 480 x 480 pixels, the iONprime CP4 KNX allows intuitive operation of various room functions. System integrators can configure up to 6 operational pages, with each page supporting up to 8 distinct functions for switching, dimming, blind adjustment, and room climate control in residential and commercial applications.

Key Features

• KNX TP room controller with built-in temperature controller functionality.
• Integrated sensors for ambient temperature, relative humidity, proximity, and brightness.
• 4-inch touch screen display with 480 x 480 pixel resolution.
• Supports switching, dimming, blind control, and room climate control operations.
• Configurable user interface supporting up to 6 pages (each managing up to 8 functions).
• Standard KNX bus connection with operating voltage of 12 – 30 V DC.
• Protection class III rating with IP 20 degree of protection.

Benefits

• Integrated sensor suite measuring temperature, relative humidity, proximity, and brightness in a single controller.
• High-resolution 4-inch touch display (480 x 480 px) for clear interface layout and effortless operation.
• Versatile operational structure supporting up to 6 customizable pages with 8 functions per page.
• Efficient power management with low bus current consumption of ≤5 mA on standard KNX TP systems.
• Wide ambient operating temperature tolerance from 0°C to 45°C suitable for various indoor environments.

Technical Specifications

Specification	Value
Operating voltage KNX	Bus voltage, ≤5 mA
Operating voltage	12 – 30 V DC
Type of connection	KNX bus terminal
Stand-by consumption	70
Protection class	III
Hand book	PDF
Information Notice EU Data Act	PDF
CE declaration of conformity	PDF
Data sheet	PDF
Flyer	PDF
briefing	PDF
Colour	Black
Ambient temperature	0°C … 45°C
Operating instructions	PDF
Type of protection	IP 20
KNX-Database (all products)	ZIP
KNX-Database (Single Product)	ZIP

Applications

• Room climate and relative humidity control in modern residential KNX installations.
• Centralized switching, dimming, and blind management in commercial office spaces.

Installation Notes

• Connect using standard KNX bus terminals, adhering to the operating voltage range of 12 – 30 V DC and ≤5 mA bus current.
• Install in dry indoor areas conforming to the IP 20 protection rating and operating ambient temperatures between 0°C and 45°C.

Developer Resources

• KNX-Database single product ZIP file
• KNX-Database all products ZIP file
• Operating instructions and technical datasheet PDF documentation
• CE declaration of conformity and handbook PDF files

FAQ

What functions can be controlled with the theben iONprime CP4 KNX?

The device enables switching, dimming, blind control, and room climate regulation across up to 6 pages, with 8 functions per page. Explore more products from theben for professional building automation projects.

Which sensors are integrated into the theben 4969300 controller?

It includes integrated sensors for temperature, relative humidity, proximity, and brightness. For certificates and current technical files, refer to the official theben product page.

What is the screen resolution and size of the display?

The device features a 4-inch touch display with a 480 x 480 pixel resolution.

What are the electrical supply requirements for this unit?

It operates on standard KNX bus voltage (≤5 mA current draw) with an operating voltage of 12 – 30 V DC.

What is the exact product model?

The order/model code for this page is 4969300. Match it against project documents before purchase.

Who is the manufacturer?

This product is manufactured by theben.

Conclusion

The theben iONprime CP4 KNX (SKU: 4969300) delivers a complete room control solution equipped with integrated temperature, humidity, proximity, and brightness sensors alongside a crisp 4-inch touch display. With capacity for up to 48 functions across 6 pages, it is an optimal selection for modern building automation projects. Installers and system integrators can review our installer purchasing support options.
