Panasonic KNX IR Interface IR100 (WRKT26115NC)

Description

Introduction

– The Panasonic KNX IR Interface IR100 (SKU: WRKT26115NC) is designed to integrate infrared-controlled devices directly into a KNX building automation topology. By learning and transmitting IR signals, this module allows system integrators to bring standalone consumer electronics—such as televisions, split air conditioners, and media players—under unified KNX control. Furthermore, incoming commands from an IR remote control can be translated into KNX telegrams to trigger automated scenes, lighting control, motorized blinds, and HVAC functions across the network. This device is part of our KNX system devices range.

– Engineered with a compact form factor measuring 37 x 38 x 11.5 mm, the IR100 unit fits easily inside standard electrical flush-mounting boxes. It operates solely on power supplied directly by the KNX bus line, eliminating the requirement for an auxiliary external power supply. Systems engineering and configuration are managed using the ETS Device Configuration App (DCA), simplifying code learning and deployment for technical consultants and system installers.

Key Features

• Bus-Powered KNX Module: Entirely powered via the KNX bus line without external auxiliary power requirements.
• Port Structure: 4 dedicated IR ports total (3 ports configured strictly as transmitters; 1 port configurable as both transmitter and receiver).
• Channel Capacity: 100 channels available for IR-to-KNX and KNX-to-IR data translation.
• Code and Macro Storage: Holds up to 250 IR device memory profiles and supports up to 16 defined macro sequences for consecutive command execution.
• Direct Split AC Control: Configured for direct KNX control of up to 4 split air conditioner units.
• ETS DCA Configuration: Designed for program setup, IR code learning, and parameter management through the ETS Device Configuration App (DCA).
• Auxiliary Functions: Includes logic gates, counting functions, scene calling, and configurable reset behavior.
• Command Timing: Supports delayed or repeating IR code transmission modes for precise device signaling.

Benefits

• Bus-Powered Operation: Receives all operational power directly from the KNX bus line, removing the need for additional power supply units or secondary wiring.
• Bidirectional Control: Supports sending IR commands to external devices via KNX telegrams, as well as triggering KNX scenes and actuation from standard handheld IR remote controls.
• Direct HVAC Integration: Capable of directly managing up to four split air conditioning units over the KNX automation system.
• Compact Form Factor: Ultra-small dimensions (37 x 38 x 11.5 mm) allow direct placement in standard electrical junction and flush-mount boxes.
• Extensive IR Memory: Stores up to 250 IR device profiles and supports up to 16 macro sequence definitions for multi-command automation.
• Integrated Auxiliary Logic: Features logic gates, counters, scene recallers, and configurable actions after system reset for advanced programming flexible execution.

Applications

• Hotel Guest Rooms: Permits guest control of climate, entertainment units, and KNX room lighting scenes using a single unified interface or remote.
• Conference and Meeting Rooms: Automatically triggers motorized screens, projectors, and lighting scenes when a presentation scenario is selected.
• Commercial and Residential Media Rooms: Provides centralized KNX automation over televisions, media players, and home cinema night modes.
• HVAC Integration: Integrates split air conditioning units and IR-supported thermostats directly into the broader KNX HVAC network.

Installation Notes

• Form Factor & Mounting: The compact module (37 x 38 x 11.5 mm) is intended for installation inside standard electrical flush-mount junction boxes close to the target IR devices.
• Wiring and Power: Connect directly to the KNX bus line using standard bus connectors. Verify that no external power supply is attached, as the device operates entirely off bus power.
• Port Setup: Verify physical routing for the 4 ports. Note that 3 ports act strictly as IR transmitters, while 1 port can be designated for both transmission and signal learning/reception.
• Procurement & BOQ Verification: When matching Bill of Quantities (BOQ) specifications, verify the exact manufacturer part number WRKT26115NC and model name Panasonic KNX IR Interface IR100 against official documentation to ensure exact compatibility.

Developer Resources

• Panasonic KNX IR Interface IR100 Reference Manual
• Panasonic KNX IR Interface IR100 User and Installation Manual
• Panasonic BAS Product Documentation for WRKT26115NC
• ETS DCA (Device Configuration App) Database Files

FAQ

Does the Panasonic IR100 require an auxiliary power supply?

No. The Panasonic KNX IR Interface IR100 receives all necessary operational energy directly from the KNX bus line. Explore more Panasonic automation devices for professional building automation projects.

How many split air conditioners can be controlled by a single IR100 module?

A single Panasonic IR100 module can directly control up to 4 split air conditioning units over the KNX system. For certificates and current technical files, refer to the manufacturer technical documentation.

How is infrared code learning handled on the IR100?

IR codes are learned using the dual-function receiver/transmitter port and managed directly through the ETS DCA (Device Configuration App).

What is the memory capacity for IR commands on this device?

The module provides 100 channels (IR to KNX and KNX to IR), can store up to 250 IR device memories, and supports up to 16 macro sequence definitions.

What is the exact product model?

The order/model code for this page is WRKT26115NC. Match it against project documents before purchase.

Who is the manufacturer?

This product is manufactured by Panasonic.

Conclusion

The Panasonic KNX IR Interface IR100 (WRKT26115NC) offers a practical, bus-powered solution for integrating infrared-controlled equipment into standard KNX automation networks. Installers and system integrators can review our professional project support options.

With support for 100 channels, 250 IR device memories, direct split AC control, and ETS DCA integration, it provides system integrators with a compact tool for AV and climate control integration.
