Inspinia A-KNX BMS Addon Module

Description

Introduction

The Inspinia A-KNX BMS Module is a dedicated hardware add-on designed to enable direct integration with KNX Twisted Pair communication media. Engineered specifically for compatibility with Inspinia smart building automation hardware, this module allows seamless bus communication while maintaining minimal power consumption on the KNX bus line. This device is part of our KNX system components range.

As part of Inspinia’s modular BMS add-on series, the A-KNX interface incorporates board-to-board isolation to ensure reliable physical and electrical connection to the main board. This series also encompasses complementary interface modules for RS485, Zigbee, Bticino SCS, and Inels Bus networks.

Key Features

• Order Code: A-KNX for dedicated KNX Twisted Pair connectivity.
• Bus Power Consumption: Approx. < 10mA for A-KNX.
• Isolation Architecture: Board-to-board type.
• Option for RS485 via Order Code A-GRS4 with board-to-board galvanic isolation.
• Option for wireless Zigbee via Order Code A-ZGB with up to 40 meters distance.
• Option for Bticino / SCS via Order Code A-SCS with < 10mA bus power consumption.
• Option for Inels Bus via Order Code A-iBUS with < 10mA bus power consumption.

Benefits

• Enables direct physical integration with KNX Twisted Pair communication media.
• Consumes minimal current from the bus, rated at approximately less than 10mA.
• Utilizes board-to-board isolation for physical hardware connection.
• Integrates into Inspinia’s modular expansion ecosystem alongside RS485, Zigbee, SCS, and iBUS interfaces.
• Provides system integrators with flexible multi-protocol building management options.

Technical Specifications

Specification	Value
A-KNX – Supported Media	KNX Twisted Pair
A-KNX – Power Consumption on Bus	Approx. < 10mA
A-KNX – Isolation Type	Board-to-board
A-GRS4 – Supported Media	RS485
A-GRS4 – Power Consumption on Bus	None
A-GRS4 – Isolation Type	Board-to-board Galvanic Isolated
A-ZGB – Supported Media	Zigbee
A-ZGB – Power Consumption on Bus	None
A-ZGB – Isolation Type	None
A-ZGB – Wireless Distance	40 mt.
A-SCS – Supported Media	Bticino / SCS
A-SCS – Power Consumption on Bus	Approx. < 10mA
A-SCS – Isolation Type	None
A-iBUS – Supported Media	Inels Bus
A-iBUS – Power Consumption on Bus	Approx. < 10mA
A-iBUS – Isolation Type	None

Applications

• Connecting Inspinia smart automation controllers to KNX Twisted Pair network installations.
• Multi-protocol building management deployments requiring modular hardware expansion for RS485, Zigbee, SCS, or Inels Bus.

Installation Notes

• Attach the module directly to the main unit using the designated board-to-board connector.
• Ensure proper network media connections match the specific module order code (e.g., KNX Twisted Pair for A-KNX).
• Verify that overall bus power consumption remains within specified device limits during commissioning.

Developer Resources

• Refer to official Inspinia product manuals and module datasheets for hardware interface details.

FAQ

What is the supported media for the A-KNX module?

The A-KNX module supports KNX Twisted Pair media. Explore more Inspinia automation devices for professional building automation projects.

How much power does the A-KNX module consume from the bus?

The power consumption on the bus for the A-KNX module is approximately less than 10mA. For certificates and current technical files, refer to the official product documentation.

What isolation type does the A-KNX module feature?

The A-KNX module features board-to-board isolation.

What other module order codes are available in this BMS series?

The series includes A-GRS4 (RS485), A-ZGB (Zigbee), A-SCS (Bticino / SCS), and A-iBUS (Inels Bus).

What is the exact product model?

The order/model code for this page is A-KNX. Match it against project documents before purchase.

Who is the manufacturer?

This product is manufactured by Inspinia.

Conclusion

The Inspinia A-KNX BMS Addon Module offers system integrators a direct, low-power solution for integrating KNX Twisted Pair communication into compatible Inspinia control platforms. Installers and system integrators can review our installer purchasing support options.
